PROAUDIO MZX84 Sonemikser, 4 soner

8 inn/4 ut. 19"/2U
MZX84 is a 4-zone mixer, 2U rack, equipped with 8 inputs and 4 assignable outputs.  Features:
It is suitable for installations where specific sound is required on different areas.
The mic 1,2,3,4, inputs have phantom power and priority function.
Gain adjustment trimmer on each channel and 3-band tones control for 1-4 channels.
Outputs with LED indicators and 2-band tones control.
Zone audio monitoring through transducer on.
Remote zone control with WP-1.MATRIX MIXER
Channels: 8 input - 4 output
AUDIO SPECIFICATIONS
Output level/impedance: 0dB/600Ohm balanced
Frequency responce: 20- 20000Hz @ 8 Ohm (±0.5 dB)
THD+N: <0.1%
Input impedance: 20kO
Signal/Noise rate: >90dB
POWER SUPPLY STAGE
Type: Switching
Operating voltage/frequency: 100/240V, 50/60Hz
FUNCTIONS
Input se
